GALVANIZED OR POWDER COATEDto RAL of choice
The structure of Lisière can remain ingalvanized steelor bepowder coateddepending on the desired result.
This allows the shelter to be adapted to the context of the site: galvanized appearance if you are looking for a more raw and technical reading, or powder-coated structure forRAL of your choiceif the project requires more architectural integration or more aligned with your charter.
A steel structure configurable between galvanized and powder-coated.
LIGHTER than solid cladding andLIMITED MAINTENANCE
The choice between Bosquet and Lisière is mainly based on the visual rendering.
The Bosquet assumes a fuller and more concealing facade. The Lisière keeps a more openwork frame, therefore a lighter presence on the site. It is well suited when you want a visible and high-quality wooden shelter, without creating a volume that is too closed or too massive in a courtyard, in front of a building or on an exposed facade.
Fuller, more concealing, more frank reading.
More openwork, lighter, more discreet reading from afar.
WATER DRAINS in the posts
On the Lisière, the water is not left to chance: it ispiped into the poststhen rejectedat the foot of the shelter.
This is a real design detail, because it avoids uncontrolled drainage on the sides or on the front. Result: a cleaner reading of the shelter, better controlled surroundings during use, and a water outlet located in a predictable location for operation.
- Integrated evacuation:water runs down the posts rather than flowing freely around the shelter.
- Localized output:it comes out at the foot of the shelter, in an identified place that is easier to manage.
- Cleaner use:this avoids sending water anywhere onto circulation areas or nearby facades.
TECHNICAL SPECIFICATIONSLISIÈRE
Galvanized steel structure guarantee: 5 yearsexcluding vandalism
STRUCTURE
- Galvanized steel or epoxy painted steel
- Rectangular beams 120 x 60 mm
- 80 x 80 mm and 80 x 60 mm columns
- RAL of your choice on painted structure
BARDAGE & TOITURE
- Wooden cladding Douglas suitable for exterior use
- Toiture en bac acier nervuré
- Gouttière en tôle d'acier pliée
- Évacuation des eaux dans les poteaux arrière
IMPLANTATION
- Platines 20 x 20 cm réglables sur 20 cm
- Concrete slab or foundation blocks recommended
- Installation on bitumen possible after study of the coating
- Only installation on pedestals or concrete slabs is guaranteed
LIVRAISON
- Delivered next to the truck
- Shelter delivered as a kit on a pallet
- Structure dimensioned according to Eurocodes
- Vent 0,601 kN/m² et neige 1,8 kN/m² selon zone
CUSTOMIZATION & OPTIONS
The same equipment levers as the Bosquet, with the visual reading specific to the Lisière
DimensionsLisière
The Lisière uses the same dimensional base as the Bosquet. You therefore keep a simple reading of the project, with a different aesthetic rendering.
| Length (m) | 4m | 5m | 6m | 7m | 8m | 10m | Custom made |
|---|---|---|---|---|---|---|---|
| Capacity (bicycles) | 8-10 | 12-14 | 16-18 | 20-22 | 24-26 | 30-32 | Contact us |
Standard version
2,13m
Passage height. The right choice for single-stage use and direct project reading.
Request a quotePLUS version
2,78m
Double Deck Compatible.
To remember when it is necessary to densify without changing the footprint.
I choose this versionFAQ Wooden bike shelterLisière
Useful answers before launching your open bike shelter project in Douglas
They share the same dimensional base and the same option logic. The difference is mainly in visual reading.Lisière further filters content remotelywhile maintaining a lighter facade than solid cladding.Bosquetassumes a more opaque and frank presence.
The cladding is inDouglas suitable for outdoor use. It is therefore a durable wooden base for the exterior. Like any exposed wood, its color will change over time, but without compromising the durability of the material.
Aconcrete slaborfoundation blocksare recommended. Laying on bitumen can be studied, but only after validation of the state of the coating by our technical teams.
Yes. TherePlus versionallows the integration of double-decker racks to increase capacity when available space is limited.
Yes. Like Bosquet, it can be completed withhoops with gripsand asolar kitdepending on the level of equipment desired.
For a surface area less than 20 m², aprior declarationis often enough. Beyond that, another regime may apply. We can help you frame this point according to your project.
Are you looking for an open wooden bike shelter that remains discreet on the site?
We help you define the right Lisière configuration according to your footprint, your target capacity and the expected level of equipment.
